| Protocols/Standards |
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, LLDP-MED, TR-069, 802.1x, TLS, SRTP, IPv6, OpenVPN® |
| Network Interfaces |
One 10/100 Mbps port with integrated PoE/PoE+ |
| Bluetooth |
Yes, integrated. Bluetooth 4.0 + EDR |
| Wi-Fi |
Yes, dual-band 2.4 & 5GHz with 802.11 a/b/g/n, WMM |
| Voice Codecs and Capabilities |
G.711µ/a, G.722 (wide-band), G.726-32, iLBC, Opus, G.729A/B in-band and out-ofband DTMF (In audio, RFC2833, SIP INFO), VAD, CNG, AEC, PLC, AJB, AGC, ANS |
| Telephony Features |
SIP Paging, Multicast Paging, call-waiting with priority override |
| HD Audio |
Yes, HD speaker with support for full-band audio |
| Speaker |
8W high-fidelity HD speaker |
| QoS |
Layer 2 QoS (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS |
| Security |
User and administrator level passwords, MD5 and MD5-sess based authentication, |
| 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1x media access |
| control |
| Multi-language |
English, French, German, Portuguese, Russian, Simplified Chinese, Spanish |
| Upgrade/Provisioning |
Firmware upgrade via TFTP / HTTP / HTTPS or local HTTP upload, mass provisioning using AES encrypted XML configuration file |
| Power & Green Energy Efficiency |
Integrated PoE (802.3af Class 3, PoE+ 802.3at Class 4) |
| Temperature and Humidity |
Operation: 0°C to 40°C Storage: -10°C to 60°C |
| Humidity: 10% to 90% Non-condensing |
| Package Content |
GSC3505 SIP Speaker, mounting kits, quick installation guide, GPL license |
| Compliance |
FCC: Part 15 (CFR 47) Class B; UL 60950 (power adapter); FCC Part 15C, FCC Part |
| 15E, MPE |
| CE : EN 55032; EN 55024; EN 61000-3-2; EN 61000-3-3; EN 60950-1; EN 301 489- |
| 1/17; EN 300 328; EN 301 893; EN 62311; RoHS |
| RCM: AS/NZS CISPR 32/24; AS/NZS 60950.1; AS/NZS 4268 |
| IC: ICES 003, RSS 247, RSP-100, RSS 102 |
| Dimensions |
215.32 x 68.7mm |
| Weight |
0.8kg |
