| Hardware Specifications |
| Copper Ports |
8 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X port |
| SFP/mini-GBIC Slots |
2 x 100/1000BASE-X SFP interface |
| Supports 100/1000Mbps dual mode and DDM |
| PoE Injector Port |
8 ports with 802.3at / af PoE injector function with port-1 to port-8 |
| Switch Architecture |
Store-and-Forward |
| Switch Fabric |
20Gbps/ non-blocking |
| Switch Throughput@64Bytes |
14.88Mpps |
| Address Table |
8K entries |
| Shared Data Buffer |
4.1 megabits |
| Flow Control |
IEEE 802.3x pause frame for full-duplex |
| Back pressure for half-duplex |
| Jumbo Frame |
10K bytes |
| Reset Button |
< 5 sec: System reboot |
| > 5 sec: Factory default |
| LED |
PWR, LNK/ACT, PoE-in-use, 1000, fan alert |
| Power Requirements |
100~240V AC, 50/60Hz, auto-sensing |
| Dimensions (W x D x H) |
330 x 155 x 43.5 mm, 1U height |
| ESD Protection |
Contact Discharge 4KV DC |
| Air Discharge 8KV DC |
| Enclosure |
Metal |
| Weight |
1687g |
| Power Consumption / Dissipation |
165 watts (max.) / 563 BTU |
| Fan |
1 x smart fan |
| Power over Ethernet |
| PoE Standard |
IEEE 802.3af / 802.3at PoE+ PSE |
| PoE Power Supply Type |
End-span |
| PoE Power Output |
Per port 52V DC, 36 watts (max.) |
| Power Pin Assignment |
1/2(+), 3/6(-) |
| PoE Power Budget |
120 watts (max.) @ 25 degrees C |
| 100 watts (max.) @ 50 degrees C |
| PoE Ability PD @ 9 watts |
8 units |
| PoE Ability PD @ 15 watts |
8 units |
| PoE Ability PD @ 30 watts |
4 units |
| Layer 2 Functions |
| Port Mirroring |
TX / RX / both |
| Many-to-1 monitor |
| VLAN |
802.1Q tagged-based VLAN |
| Up to 256 VLAN groups, out of 4094 VLAN IDs |
| 802.1ad Q-in-Q tunneling |
| Voice VLAN |
| Protocol VLAN |
| Private VLAN (Protected port) |
| GVRP |
| Link Aggregation |
IEEE 802.3ad LACP and static trunk |
| Supports 8 groups of 8-port trunk |
| Spanning Tree Protocol |
STP, IEEE 802.1D Spanning Tree Protocol |
| RSTP, IEEE 802.1w Rapid Spanning Tree Protocol |
| MSTP, IEEE 802.1s Multiple Spanning Tree Protocol |
| IGMP Snooping |
IGMP (v2/v3) snooping |
| IGMP querier |
| Up to 256 multicast groups |
| MLD Snooping |
MLD (v1/v2) snooping, up to 256 multicast groups |
| Access Control List |
IPv4/IPv6 IP-based ACL / MAC-based ACL |
| QoS |
8 mapping ID to 8 level priority queues |
| - Port number |
| - 802.1p priority |
| - 802.1Q VLAN tag |
| - DSCP field in IP packet |
| Traffic classification based, strict priority and WRR |
| Security |
IEEE 802.1X port-based authentication |
| Built-in RADIUS client to co-operate with RADIUS server |
| RADIUS / TACACS+ user access authentication |
| IP-MAC port binding |
| MAC filtering |
| Static MAC address |
| DHCP Snooping and DHCP Option82 |
| STP BPDU guard, BPDU filtering and BPDU forwarding |
| DoS attack prevention |
| ARP inspection |
| IP source guard |
| Management Functions |
| Basic Management Interfaces |
Web browser / Telnet / SNMP v1, v2c |
| Firmware upgrade by HTTP / TFTP protocol through Ethernet network |
| Remote / Local Syslog |
| System log |
| LLDP protocol |
| SNTP |
| Secure Management Interfaces |
SSH, SSL, SNMP v3 |
| SNMP MIBs |
RFC 1213 MIB-II |
| RFC 1215 Generic Traps |
| RFC 1493 Bridge MIB |
| RFC 2674 Bridge MIB Extensions |
| RFC 2737 Entity MIB (Version 2) |
| RFC 2819 RMON (1, 2, 3, 9) |
| RFC 2863 Interface Group MIB |
| RFC 3635 Ethernet-like MIB |
| Standards Conformance |
| Regulation Compliance |
FCC Part 15 Class A, CE, LVD |
| Standards Compliance |
IEEE 802.3 10BASE-T |
| IEEE 802.3u 100BASE-TX/100BASE-FX |
| IEEE 802.3z Gigabit SX/LX |
| IEEE 802.3ab Gigabit 1000T |
| IEEE 802.3x flow control and back pressure |
| IEEE 802.3ad port trunk with LACP |
| IEEE 802.1D Spanning Tree protocol |
| IEEE 802.1w Rapid Spanning Tree protocol |
| IEEE 802.1s Multiple Spanning Tree protocol |
| IEEE 802.1p Class of Service |
| IEEE 802.1Q VLAN tagging |
| IEEE 802.1x Port Authentication Network Control |
| IEEE 802.1ab LLDP |
| IEEE 802.3af Power over Ethernet |
| IEEE 802.3at Power over Ethernet Plus |
| RFC 768 UDP |
| RFC 793 TFTP |
| RFC 791 IP |
| RFC 792 ICMP |
| RFC 2068 HTTP |
| RFC 1112 IGMP version 1 |
| RFC 2236 IGMP version 2 |
| RFC 3376 IGMP version 3 |
| RFC 2710 MLD version 1 |
| RFC 3810 MLD version 2 |
